The Vantage Z1 Bulkhead Assembly Kit is designed to provide a secure and efficient connection point in various applications. Ideal for both professional and DIY projects, this kit ensures reliable performance and ease of installation in any setting.
| Spare Parts Name |
Quantity |
| Wire Harness Clip, 0.500 in ID - 194971 |
1 |
| 10-32 UNC Muffler - 382934 |
4 |
| Black Polyurethane Tubing, 1/8 in OD x 0.079 in ID - 386953 |
2 |
| Blue Polyurethane Tubing, 1/8 in OD x 1/16 in ID - 386956 |
1 |
| Quick-Disconnect Female Black Bulkhead Fitting, 10-32 Thread - 195402 |
1 |
| Union Fitting, 10-32 Thread to 1/8 in Tube - 387427 |
5 |
| Quick-Disconnect Fitting, 1/4 in Y x 1/8 in - 197668 |
1 |
| Hex Nut, M3 x 0.5 - 7242811 |
2 |
| Socket Cap Screw, M3 x 5mm - 387978 |
4 |
| Socket Cap Screw, M3 x 10mm - 387981 |
5 |
| Button Head Screw, M4 x 0.7, 6mm Length - 7226304 |
7 |
| Quick-Disconnect Female Green Bulkhead Fitting - 7201192 |
2 |
| MAC44 4-Way Air Valve, 24V - 7201334 |
2 |
| Plug, 10-32 Thread - 7208633 |
1 |
| Quick-Disconnect Female Clear Bulkhead Fitting, M5 - 7209918 |
1 |
| Blank Self-Laminating Label - 7220555 |
2 |
| Small Blank Component Label - 7220558 |
2 |
| Mini Dual Female Bulkhead Fitting - 7221822 |
2 |
| Bulkhead to MAC Valve Cable - 7233014 |
2 |
| Straight Fitting, 10-32 x 1/4 in OD - 7239683 |
4 |
| Hex Nut with Tooth Washer, M5 - 7254144 |
1 |
| Samtec 30-Pin to CPC Cable - 7289188 |
1 |
| Head 1 Right Bulkhead Cover - 7290928 |
1 |
| Head 1 Front Bulkhead Cover - 7290929 |
1 |
| Tested Bulkhead Printed Circuit Assembly - 7297725 |
1 |
| Vantage Z1 Rear Bulkhead Cover - 6115935 |
1 |
| Vantage Bulkhead Cooler Cover - 6131369 |
1 |
| Bulkhead Analog Input and Output Cable - 6124697 |
1 |
| Bulkhead Digital Input and Output Cable - 6124698 |
1 |
| D-Sub Stainless Steel Hex Post, 4-40 x 3/16 in - 382564 |
4 |
| Green Quick-Disconnect Bulkhead Female Fitting - 7201192 |
2 |
| Clear Quick-Disconnect Bulkhead Female Fitting, M5 - 7209918 |
1 |
| Straight Fitting, 10-32 Thread x 1/4 in OD - 7239683 |
4 |
| Z2 Left Bulkhead Cover - 7290948 |
1 |
| Z2 Front Bulkhead Cover - 7290949 |
1 |
| Black 10-32 Quick-Disconnect Bulkhead Female Fitting - 195402 |
1 |
| 10-32 Thread to 1/8 in Tube Union Fitting - 387427 |
5 |
| Quick-Disconnect Y Fitting, 1/4 in x 1/8 in - 197668 |
1 |
| Button Head Screw, M4 x 0.7 x 6mm - 7226304 |
7 |
| Hex Nut, M3 - 7242811 |
2 |
| Self-Laminating Blank Label - 7220555 |
2 |
| M5 Hex Nut with Tooth Lock - 7254144 |
1 |
| Tested Bulkhead PCA Assembly - 7297725 |
1 |
| Vantage Z2 Rear Bulkhead Cover - 6115937 |
1 |
| Bulkhead Analog Input/Output Cable - 6124697 |
1 |
| Bulkhead Digital Input/Output Cable - 6124698 |
1 |
| Stainless Steel D-Sub Hex Post, 4-40 x 3/16 in - 382564 |
4 |
